Modular & Skids
Chemical Plant Equipment Skids & Platforms
- Client
- Confidential — Chemical Producer
- Location
- Jubail Industrial City
- Sector
- Petrochemical
- Discipline
- Modular & Skids
- Fabricated Weight
- 520 t
- Duration
- 8 months
- Year
- 2025
- Completed
- February 2025
Overview
Pump skids, equipment support structures and maintenance access platforms for a chemical plant debottlenecking project.
Skids were delivered complete with baseplates, grouting details, pipework stubs and instrument supports, so mechanical installation reduced to setting, levelling and connecting.
Access platforms, stairs and handrails were designed to the client's own engineering standard and trial-fitted in the shop to confirm clearances against the equipment model.
Scope of Work
- Pump and equipment skids with baseplates
- Instrument and pipework stub supports
- Maintenance access platforms and stairs
- Client engineering standard compliance
- Shop trial fit against the equipment model
